Data Moving#

Similar to amd64, the mov instruction can be used. However, literal values must be prefixed with the # symbol!

mov x1, #0x1337

aarch64 registers are 64 bits in size, but the mov instruction only works with 16 bit immediate values.

In order to move larger literal values, the mov and movk instructions are needed.

movk loads a value into the destination register with a specific bitshift, retaining all other bytes.

mov x1, #0xbeef
movk x1, #0xdead, lsl #16

Results in x1 containing the value 0xdeadbeef.

Load / Store#

Memory addresses cannot be directly accessed in aarch64. Only registers can be operated on.

Values must be loaded from memory to a register with ldr and written back to memory via str.

For example, to increment a value located at memory address 0x1337, the following instructions would be needed:

mov x1, #0x1337
ldr x0, [x1]
add x0, x0, #1
str x0, [x1]

Locations memory addresses can also be offset from. Example:

mov x1, #0x4000
ldr x0, [x1, #8]

Would load 8 bytes stored at 0x4008 into x0.

Consecutive memory addresses can be loaded and stored in a single instruction as a pair:

ldp x0, x1, [sp]
stp x0, x1, [sp]

Above is equivalent to the following instructions:

ldr x0, [sp]
ldr x1, [sp, #8]
str x0, [sp]
str x1, [sp, #8]

Stack#

aarch64 does not have the push/pop instructions to work with the stack, instead, you must use ldr and str to retrieve values from the stack.

Fortunately, both ldr and str have the ability to increment the address passed in pre/post access.

This feature can be used to perform the same action:

Popping the stack would be of the form:

ldr x1, [sp], #16

This loads the value located at the stack pointer into register x1 and then adds 16 to the stack.

Pushing to the stack would be of the form:

str x1, [sp, #-16]!

This subtracts 16 from the stack pointer and then stores the value in x1 at sp.

NOTE

In aarch64, the stack pointer must be 16 byte aligned! Accessing the stack pointer when it is not properly aligned will result in a fault!

There is different syntax for accessing memory at an offset, pre-indexing, and post-indexing. All of these forms are used extensively in aarch64.

Example 1#

Function form calc_avg(ptr, count)

where:

• ptr is the start of the array
• count is the number of 64 bit numbers in the array

mov x0, ptr
mov x1, 64
bl calc_avg

calc_avg:
    stp x29, x30, [sp, #-0x10]!
    mov x29, sp
    mov x2, xzr // sum = 0
    mov x3, x1  // original_count = count
loop:
    cbz x1, done
    ldr x4, [x0], #0x8
    add x2, x2, x4
    subs x1, x1, #0x1
    b.ne loop
done:
    sdiv x0, x2, x3
    mov sp, x29
    ldp x29, x30, [sp], #0x10
    ret

Example 2#

Function form fib(pos)

where:

• pos is position in the fibonacci sequence

// fib(0) = 0
// fib(1) = 1
// fib(n) = fib(n-1) + fib(n-2)

fib:
    stp x29, x30, [sp, #-0x10]!
    mov x29, sp
    cbz x0, .ret0       // if pos == 0, return 0
    cmp x0, #0x1
    b.eq .ret1          // if pos == 1, return 1

    mov x1, #0x0        // prev = 0x0
    mov x2, #0x1        // curr = 0x1
    mov x3, x0          // counter = pos
.loop:
    add x4, x1, x2      // next = prev + curr
    mov x1, x2          // prev = curr
    mov x2, x4          // curr = next
    subs x3, x3, #0x1
    cmp x3, #0x1
    b.gt .loop

    mov x0, x2          // return curr
    mov sp, x29
    ldp x29, x30, [sp], #0x10
    ret
.ret0:
    mov x0, xzr
    mov sp, x29
    ldp x29, x30, [sp], #0x10
    ret
.ret1:
    mov x0, #0x1
    mov sp, x29
    ldp x29, x30, [sp], #0x10
    ret
